Forest fire fighting
Protecting lives during large-scale forest fires
A small amount of water halon fire extinguishing agent
can achieve the maximum effect, and the use of environmentally friendly
AKAGE fire extinguishing agent, Quickly save lives,
fire extinguishing agent for large-scale forest fires and other fires.

AKAGE fire extinguishing agent has the characteristics
of high specific heat capacity and strong isolation
In the lithium battery fire and solar panel fire
It is more efficient than other fire extinguishing agents in the process of extinguishing
AKAGE fire extinguisher
The hydrophilicity of the gel molecules makes them have
strong water retention and high adhesion.
It has good fluidity at low temperatures and sufficient viscosity at high temperatures.
While making it convenient to use, it also increases the
overall cooling effect of the lithium battery.
After the AKAGE fire extinguishing agent was sprayed,
the temperature of the
battery pack quickly dropped to Thermal runaway temperature below 200°C
AKAGE fire extinguishing agent has a certain limiting effect on jet flames.
And it can hinder the heat transfer between multiple batteries;
After using the AKAGE fire extinguisher, the batteries did not reignite.
This shows that AKAGE has a good fire extinguishing effect on lithium battery fires.
AKAGE water sea dragon gel fire extinguisher Mechanical foam "gel type" fire extinguisher in stainless steel bottle.
Mechanical foam with Fire Department type approval number:
FE-A113002 and AE-A112004
High molecular gel is added to the fire extinguishing agent.
Spray the gel fire extinguisher evenly on the solid combustible material
to immediately Forming a thicker gel film, it can isolate the air,
cool the surface of the object,
It consumes a lot of heat and achieves good fire-blocking and
fire-extinguishing effects.
It can effectively extinguish Class A fires in forests and grasslands.

The carbon dioxide and water vapor produced after the high water content gel
is burned are non-combustible and non-toxic.
Use AKAGE to extinguish fire, which is efficient, environmentally friendly and
water-saving in terms of fire extinguishing function;

A fire truck equipped with AKAGE fire extinguisher,
It is equivalent to 10 fire trucks equipped with tap water.

The principles and methods of fire fighting tactics are basically the
same as those of water fire fighting.
When using AKAGE to extinguish Class A fires, its fire extinguishing effect is
more than 6 times that of water.
When extinguishing forest and grassland fires, its fire extinguishing effect is
more than 10 times that of water.
The most important thing is that the fire extinguishing agent of
"AKAGE Fire Extinguisher AE-A112004" is
"Pure water" makes "non-conductive",
which is actually suitable for solar panel fire extinguishers and
lithium battery fire extinguishers The basic requirements.
The "Water Halon Mechanical Foam Fire Extinguishing Agent AE-A112004"
which has been approved by the Fire Department Adding AKAGE allows
this fire extinguisher to lock in a large amount of moisture,
increasing the fire extinguishing effect by 6 times.

 At the same time, it can also quickly cool down the burning object,
that is, on the surface of the solar panel fire object Forms a gelatinous
covering layer to isolate the air and inhibit the diffusion of toxic gases.

To achieve the purpose of controlling the spread of fire and
extinguishing fire quickly and effectively.
The AKAGE remaining after use is environmentally friendly and can be
naturally decomposed into water and carbon dioxide.

 Water Halon fire extinguisher: Non-human factors, three-year warranty.
It is advisable to check the pressure gauge pointer from time to time or
every three months to see if it is pointing to the middle green area.
If it is lower than the green zone (＜10.5kgf/cm²),
it should be sent to the maintenance department of AKA Halon Tainan Factory.
Perform routine inspections on the bottle, pressure gauge, spray hose, gasket,
O-ring, and handle valve. And replenish fire extinguishing agent and driving gas.

Each AKAGE fire extinguisher has a unique laser engraved product number.
"Unique ID Number" The production date, production conditions, fire extinguishing
agent filling amount, storage pressure, Output time, total weight, etc.
The manufacturing date is marked on the bottom of the bottle, such as
250309-8, which means March 9, 2025 The 8th produced.
When shipped, 250309-8 will also be noted on the warranty information,
which is valid for three years.
akali400
SP1
 SP2
SP4 sp4
CA1 CA2
CA3 CA4
Solar Panel Fire Extinguisher - AKAGE
Lithium Battery Fire Extinguisher - AKAGE

AKAGE Chemical Structure
[C6H7O2(OH)x(OCH2COONa)y]n+AlCl3


AKAGE AKAGE700 AKAGE900 AKAGE2L AKAGE3L AKAGE6L AKAGE9L
Brand AKAGE AKAGE AKAGE AKAGE AKAGE AKAGE
Type Portable Portable Portable Portable Portable Portable
Major S-3-AB S-3-AB S-3-AB S-3-AB S-3-AB S-3-AB
Content 700g 900g 2L 3L 6L 9L
Pressure 1.37Mpa 1.37Mpa 1.37Mpa 1.37Mpa 1.37Mpa 1.37Mpa
Bottle 304L 304L 304L 304L 304L 304L
Size 30-7.6-7.6 33-8.6-8.6 43-15-11 45-13-13 53-16-16 53-18-18
EX.Agent 700g 900g 1.5KG 4.5KG 6.5KG 8KG
Weight 1.4KG 1.7KG 3KG 5KG 9KG 11KG
Discharge ≧15 Sec. ≧20 Sec. ≧25 Sec. ≧30 Sec. ≧40 Sec. ≧60 Sec.
Insufflation ≧3m ≧3m ≧5m ≧5m ≧5m ≧5m
WaterPressure 28 kgf/cm² 28 kgf/cm² 28 kgf/cm² 28 kgf/cm² 28 kgf/cm² 28 kgf/cm²
Templeture -20~40℃ -20~40℃ -20~40℃ -20~40℃ -20~40℃ -20~40℃
Conductive ≧40kV/mm ≧40kV/mm ≧40kV/mm ≧40kV/mm ≧40kV/mm ≧40kV/mm
Efficacy A1B10CDF A1B10CDF A1B20CDF A2B20CDF A2B30CDF A2B30CDF
Valid/Year 3 3 3 3 3 3
ProductionDate 250220 250220 250220 250220 250220 250220

1P 700gm
 Fire Extinguisher AKAGE 700
Best For EV Lithium Battery Fire Extinguisher Stainless Steel Bottle
 AKAGE700

Lithium Battery, Solar Panel Fire Extinguisher AKAGE 700
Lithium Battery, Solar Panel Fire Extinguisher
Brand: AKAGE
Model: AKAGE700
Main ingredient: S-AB-3
Content: 700gm
Type: Gel fire extinguisher
Dimensions: 11.81” x 3” (bottle height 30cm x bottle diameter 7.60cm)
Total weight: 3.09 lbs. (1.20-1.40 kg)
Drive gas: Nitrogen 1.50Mpa
Spray time: ≧10 seconds
Spray distance: ≧3 meters
Water pressure test: 28kgf/cm²
Using temperature: -20℃~40℃ suitable for winter use
Dielectric strength: ≧36KV/mm
Fire extinguishing efficiency: A1, B2, C, D, F/K
Shelf life: 3 years
Production date: marked on the bottom of the bottle

3P 900gm
 Fire Extinguisher AKAGE 900 1L
 Best For EV Lithium Battery Fire Extinguisher Stainless Steel Bottle
 AKAGE900

Lithium Battery, Solar Panel Fire Extinguisher AKAGE 900
Lithium Battery, Solar Panel Fire Extinguisher
Brand: AKAGE
Model: AKAGE900
Main ingredient: S-AB-3
Content: 1L
Type: Gel fire extinguisher
Dimensions: 13.3” x 3.4” (bottle height 33.80cm x bottle diameter 8.60cm)
Total weight: 3.36 lbs. (1.65-1.90 kg)
Drive gas: Nitrogen 1.50Mpa
Spray time: ≧15 seconds
Spray distance: ≧3 meters
Water pressure test: 28kgf/cm²
Using temperature: -20℃~40℃ suitable for winter use
Dielectric strength: ≧36KV/mm
Fire extinguishing efficiency: A2, B4, C, D, F/K
Shelf life: 3 years
Production date: marked on the bottom of the bottle
AKA2L-1JIU

5P 2000gm
 Fire Extinguisher AKAGE 2000 2L
Best For EV Lithium Battery Fire Extinguisher Stainless Steel Bottle
 AKAGE2000

Lithium Battery, Solar Panel Fire Extinguisher AKAGE 2000
Lithium Battery, Solar Panel Fire Extinguisher
Brand: AKAGE
Model: AKAGE2000
Main ingredient: S-AB-3
Content: 2L
Type: Gel fire extinguisher
Dimensions: 16.93” x 5.91” (bottle height 43cm x bottle diameter 10.60cm)
Total weight: 5.21 lbs. (2.70-2.95 kg)
Drive gas: Nitrogen 1.50Mpa
Spray time: ≧20 seconds
Spray distance: ≧3 meters
Water pressure test: 28kgf/cm²
Using temperature: -20℃~40℃ suitable for winter use
Dielectric strength: ≧36KV/mm
Fire extinguishing efficiency: A2, B4, C, D, F/K
Shelf life: 3 years
Production date: marked on the bottom of the bottle
AKA3L-1

10P 3000gm
 Fire Extinguisher AKAGE 3000 3L
Best For EV Lithium Battery Fire Extinguisher Stainless Steel Bottle
 AKAGE3000

Lithium Battery, Solar Panel Fire Extinguisher AKAGE 3000
Lithium Battery, Solar Panel Fire Extinguisher
Brand: AKAGE
Model: AKAGE3000
Main ingredient: S-AB-3
Content: 3L
Type: Gel fire extinguisher
Dimensions: 17.32” x 5.12” (bottle height 44cm x bottle diameter 13cm)
Total weight: 10 lbs. (4.85 kg)
Drive gas: Nitrogen 1.50Mpa
Spray time: ≧20 seconds
Spray distance: ≧3 meters
Water pressure test: 28kgf/cm²
Using temperature: -20℃~40℃ suitable for winter use
Dielectric strength: ≧36KV/mm
Fire extinguishing efficiency: A3, B6, C, D, F/K
Shelf life: 3 years
Production date: marked on the bottom of the bottle

15P 4000gm
 Fire Extinguisher AKAGE 4000 4L
Best For EV Lithium Battery Fire Extinguisher Stainless Steel Bottle
 AKAGEi4000

Lithium Battery, Solar Panel Fire Extinguisher AKAGE 4000
Lithium Battery, Solar Panel Fire Extinguisher
Brand: AKAGE
Model: AKAGE4000
Main ingredient: S-AB-3
Content: 4L
Type: Gel fire extinguisher
Dimensions: 17.32” x 5.12” (bottle height 44cm x bottle diameter 13cm)
Total weight: 10 lbs. (4.85 kg)
Drive gas: Nitrogen 1.50Mpa
Spray time: ≧20 seconds
Spray distance: ≧3 meters
Water pressure test: 28kgf/cm²
Using temperature: -20℃~40℃ suitable for winter use
Dielectric strength: ≧36KV/mm
Fire extinguishing efficiency: A3, B6, C, D, F/K
Shelf life: 3 years
Production date: marked on the bottom of the bottle

20P 6000gm
 Fire Extinguisher AKAGE 6000 6L
Best For EV Lithium Battery Fire Extinguisher Stainless Steel Bottle
 AKAGEi6000

Lithium Battery, Solar Panel Fire Extinguisher AKAGE 6000
Lithium Battery, Solar Panel Fire Extinguisher
Brand: AKAGE
Model: AKAGE6000
Main ingredient: S-AB-3
Content: 3L
Type: Gel fire extinguisher
Dimensions: 20.87” x 6.3” (bottle height 53cm x bottle diameter 16cm)
Total weight: 19.85 lbs. (9 kg)
Drive gas: Nitrogen 1.50Mpa
Spray time: ≧30 seconds
Spray distance: ≧5 meters
Water pressure test: 28kgf/cm²
Using temperature: -20℃~40℃ suitable for winter use
Dielectric strength: ≧36KV/mm
Fire extinguishing efficiency: A4, B8, C, D, F/K
Shelf life: 3 years
Production date: marked on the bottom of the bottle

30P 9000gm
 Fire Extinguisher AKAGE 9000 9L
Best For EV Lithium Battery Fire Extinguisher Stainless Steel Bottle
 AKAGEi9000

Lithium Battery, Solar Panel Fire Extinguisher
Brand: AKAGE
Model: AKAGE9000
Main ingredient: S-AB-3
Content: 10L (2.5Gallon)
Type: Gel fire extinguisher
Dimensions: 20.87” x 7.10” (bottle height 53cm x bottle diameter 18cm)
Total weight: 30.87 lbs. (14 kg)
Drive gas: Nitrogen 1.50Mpa
Spray time: ≧30 seconds
Spray distance: ≧5meters
Water pressure test: 28kgf/cm²
Using temperature: -20℃~40℃ suitable for winter use
Dielectric strength: ≧36KV/mm
Fire extinguishing efficiency: A6, B10, C, D, F/K
Shelf life: 3 years
Production date: marked on the bottom of the bottle

33P 10000gm
 Fire Extinguisher AKAGE 10000 10L
Best For EV Lithium Battery Fire Extinguisher Stainless Steel Bottle
 AKAGE10000

Lithium Battery, Solar Panel Fire Extinguisher AKAGE 10000
Lithium Battery, Solar Panel Fire Extinguisher
Brand: AKAGE
Model: AKAGE10000
Main ingredient: S-AB-3
Content: 12L
Type: Gel fire extinguisher
Dimensions: 23.62” x 7.10” (bottle height 60cm x bottle diameter 18cm)
Total weight: 33.10 lbs. (15 kg)
Drive gas: Nitrogen 1.50Mpa
Spray time: ≧30 seconds
Spray distance: ≧5 meters
Water pressure test: 28kgf/cm²
Using temperature: -20℃~40℃ suitable for winter use
Dielectric strength: ≧36KV/mm
Fire extinguishing efficiency: A8, B12, C, D, F/K
Shelf life: 3 years
Production date: marked on the bottom of the bottle

35P 12000gm
 Fire Extinguisher AKAGE 12000 12L
Best For EV Lithium Battery Fire Extinguisher Stainless Steel Bottle
 AKAGE12000

Lithium Battery, Solar Panel Fire Extinguisher AKAGE 12000
Lithium Battery, Solar Panel Fire Extinguisher
Brand: AKAGE
Model: AKAGE12000
Main ingredient: S-AB-3
Content: 14L
Type: Gel fire extinguisher
Dimensions: 25.60” x 7.10” (bottle height 65cm x bottle diameter 18cm)
Total weight: 35.28 lbs. (16 kg)
Drive gas: Nitrogen 1.50Mpa
Spray time: ≧30 seconds
Spray distance: ≧5 meters
Water pressure test: 28kgf/cm²
Using temperature: -20℃~40℃ suitable for winter use
Dielectric strength: ≧36KV/mm
Fire extinguishing efficiency: A10, B14, C, D, F/K
Shelf life: 3 years
Production date: marked on the bottom of the bottle

66-1 66-2
AKAGE Lithium Battery & Solar Panel
Fire Extinguishers
700ml, 980ml, 2L, 3L, 6L, 9L, 20L and 40L
FK-5-1-12 Halon Fire Extinfuisher System
One Touch Fire Extinguisher Auto Filling - Refilling Machine
7308 Filling Machine
Lithium Battery & Solar Panel Fire Extinguisher AKAGE
AKALI     AKAGE
 鋰電池專用滅火器   太陽能板滅火器
AKALI   AKAGE
Fire Detection Tube Halon      AKA Halon  Water Halon  Fire Extinguisher MRI

探火管滅火器  赤海龍滅火器900  水海龍滅火器  赤海龍MRI滅火器

火燒車    消防士   寺廟古文物滅火器  家用滅火器  飛機輕航機

e-Mail Us      Payment     SkyPe: autopure     mexa@autopure.com

MEXA CO., LTD. (Since 1979)
AKA HALON CO., LTD.
Tel. +886-2-23657700 Fax.+886-2-23657702
Office: 7F., No. 14 Anmin Street, Xindian District, New Taipei City, Taiwan 231071
 挺譽貿易有限公司
 赤海龍有限公司
總公司:新北市新店區安民街14號7樓

 Factory :No. 66 Kung Ming 2nd Road, Tsun Tou Liau Industry Area, Tainan 709, Taiwan Tel.09-1019-6666    FACTORY MAP
autopureHOME

www.autopure.com

abcdk fire extinguisher fire distinguisher fire ext fire fire extinguisher en fire extinguisher fire and fire extinguisher
kitchen fire extinguisher kitchen extinguisher fire equipment servicing extinguisher distinguisher fire extinguisher types

types of extinguishers kinds of fire extinguisher types of fires and extinguishers fire cylinder type fire distinguisher types

types of fire and fire extinguisher abc fire extinguisher abc extinguisher electrical fire extinguisher fire extinguisher for electrical fire
electrical extinguisher co2 fire extinguisher car fire extinguisher home fire extinguisher kidde fire extinguisher halon fire extinguisher

halon extinguisher fire extinguisher for house kidde extinguisher fire extinguisher in car water fire extinguisher water extinguisher

carbon dioxide fire extinguisher dry chemical fire extinguisher lowes fire extinguisher fireball extinguisher
carbon dioxide extinguisher abc dry chemical fire extinguisher fire extinguisher lowe's dry chemical extinguisher
dry chem extinguisher small fire extinguisher amerex fire extinguisher 5lb fire extinguisher best fire extinguisher for home
boat fire extinguisher fire extinguisher brackets 5 pound fire extinguisher fire extinguisher mounts

滅火器 滅火器口訣 滅火器種類 滅火器 價格 消防設備 消防器材 車用滅火器 滅火器系列產品
滅火器英文 Fire Extinguisher 滅火器Fire Ex. 滅火器哪裡買 家用滅火器 拉瞄壓掃
滅火器認可基準 海龍滅火器 赤海龍滅火器 Novec 1230

 海龍滅火器HALON海龍1211（HALON 1211 – CF2ClBr）海龍 1301（HALON 1301 – CF3Br）鹵化烷
HFC-23（FE-13）、HFC-236fa（FE-36）六氟丙烷 236fa 、HFC-227ea（FM-200、NAF S125）
七氟丙烷 227ea、HCFC-123（Halotron I）hcf-236 fe-36 新海龍 naf-236 高溫高效能環保氣體滅火器10型20型
hfc-236 海龍 環保氣體 滅火器 車用 廚房 家庭用 蓄壓式 5P 10P hfc-227 NAF滅火器 潔淨藥劑滅火器
二氧化碳滅火器 乾粉滅火器 強化液滅火器 中性強化液滅 火器 自動滅火設備 自動撒水滅火設備
金屬火災滅火器 消防設備師 消防設備士 消防安全 鋰電池火災 鋰電持滅火器 太陽能板滅火器
 太陽能消防法規 太陽能 板 防火 太陽能火災案例太陽能 斷 電
太陽能 板 火警 光電板 火災 提升太陽光電發電設備安全管理指導原則 消防機關搶救太陽光電設備火災指導原則
 PV Stop extinguisher Pressure Fire extinguisher PV Stop extinguisher price Buy Fire Extinguisher Price of Fire Extinguisher How to purchase fire extinguisher
